Wiring harness: Stable signal transmission

Structure: Supports design modification

After-sales service: Easy maintenance and repair

Temperature acquisition: Excellent moisture resistance

1. Isolation plate: Fireproof and flame retardant. Made of PC+ABS, PA66 and other materials.

2. Acquisition end housing: Pure nickel housing with thin wall, fast thermal conductivity and good welding penetration performance.

3. 1060 aluminum busbar: Lightweight structure, low impedance and fast heat dissipation.

4. Connection & fixing: Laser welding, firm and attractive appearance with high automation level.

5. High sensitivity and fast response (the accuracy of resistance value and B-value can reach ±1% respectively).

6. The finished product withstands voltage up to 4200VDC.

7. Built-in high-reliability single-ended resistor, equipped with patented internal structure technology, with a service life of up to 20 years.

Bracket: Optional injection molded or blister molded isolation plate + wire groove;

Acquisition assembly: Optional wiring harness, FPC, PCB, FFC;

Temperature sensing wire: Optional epoxy head, OT terminal, nickel terminal (all equipped with NTC);

Connection method: Optional glue dispensing, screw fastening, ultrasonic welding or laser welding.

Industrial and Commercial Energy Storage, Telecom Energy Storage, Home Energy Storage, Portable Energy Storage
