Material: Injection-molded or blister-molded isolation plates / aluminum busbars, etc.
Operating temperature range: -50~150℃
1. Isolation plate: Fireproof and flame-retardant. Made of materials such as PC+ABS or PA66.
2. Sensing end housing: Pure nickel housing with thin wall thickness, fast heat conduction and excellent welding penetration performance.
3. 1060 aluminum busbar: Lightweight structure, low impedance and fast heat dissipation.
4. Connection and fixing: Laser welding, featuring firm structure, neat appearance and high automation.
5. High sensitivity and rapid response (the accuracy of resistance value and B-value can both reach ±1%).
6. The finished product boasts a withstand voltage up to 4200VDC.
7. Built-in high-reliability single-ended resistor with patented internal structure technology, achieving a service life of up to 20 years.
Bracket: Optional injection-molded or blister-molded isolation plate plus wire duct;
Acquisition assembly: Optional wiring harness, FPC, PCB and FFC;
Temperature sensing acquisition wire: Optional epoxy head, OT terminal and nickel terminal (all equipped with NTC);
Connection method: Optional glue dispensing, screw fastening, ultrasonic welding or laser welding.
Industrial & Commercial, Telecom, Residential and Portable Energy Storage
